EpiCool Platinum, Gold, and Silver for PhotoRejuvenation & Hair Removal

What's unique about EpiCool?
How does EpiCool work in comparison to the IPL® Quantum SR?
EpiCool Package Benefits
EpiCool Platinum using VascuLight-HR | EpiCool Platinum using EpiLight
EpiCool Gold using VascuLight-HR | EpiCool Gold using EpiLight
EpiCool Silver using VascuLight-HR | EpiCool Silver using EpiLight
Becoming a Distributor

What's unique about EpiCool?

Skin rejuvenation is one of the fastest growing treatment programs in the aesthetic laser market.  Physicians all over the world are coming up with their own techniques (or "settings") for maximum results with various devices. However, too often the basis for these techniques is not scientifically justified and the results are dependent upon external factors such as skin type, equipment used, age of the IPL heads, inconsistent locations of irradiation, and variations in the distance from skin during irradiation.

EpiCool's approach is based on controlling several aspects of treatment methodologies, such as the temperature of the epidermis, so that the settings can be maximized for treatment results rather than compromised by the side effects. The use of the EpiCool system as an integrated component of PhotoRejuvenation has allowed OptoGenesis™ to develop a treatment program for use with either the EpiLight or VascuLight HR. This treatment program includes specific settings for skin types up to V and provides the greatest skin rejuvenation results while effectively eliminating side effects.



How does EpiCool work in comparison to the IPL® Quantum SR?

The IPL Quantum SR uses an 8x34 crystal and a built-in thermoelectric cooling device with a quartz interface and a two-second pulse. While the built-in cooling device is more ergonomically satisfactory, with a quartz crystal the temperature can be up to 8 degrees C hotter at the center of the interface than at the edge.  The short 2-second irradiation also does not allow epidermis sufficient time to be cooled properly for high-energy light delivery.  Consequently, practitioners should be careful with higher energies to minimize the possibility of burning the patient.

The EpiCool Desktop provides a handle that attaches to the ESC handpiece that includes a epi-adapter that fits over the end of the crystal.  This cryojacket uses a sapphire interface, one of the most highly heat-conductive materials available. When coupled with EpiCool's microcomputer interface, the EpiCool can control the temperature of the epidermis within +/-1 degrees C. Likewise, with the 10x45 crystal, the practitioner can actually cover a greater area in less time than an IPL-Quantum SR, in spite of the three-second-pulse interval. Finally, EpiCool packages provide the following benefits:



EpiCool Package Benefits

• Increases the practitioners' Return On Investment (ROI) on their EpiLight or VascuLight HR investment.
• Provides consistent higher energies than the IPL Quantum SR system with less impact on the epidermis.
• Provides faster treatment sessions than the Quantum SR system.
• Requires only a 110V outlet in the U.S., instead of a costly 220-volt dedicated outlet.
• Permits superior treatment of small areas with special 8x15 crystal.
• Utilizes scientifically established parameter settings in a very simple format.  Parameters for each treatment session, for skin types I through V,



EpiCool Platinum using VascuLight-HR

This package includes a fast 3-second VascuLight, as well as an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals.  The attachment for the YAG laser head is included.  This complete package enables users to perform Photo Rejuvenation, hair removal, and leg vein treatments. One-year warranty on the EpiCool and VascuLight-HR is included. Full training and one year manual update is included.



EpiCool Platinum using EpiLight

This package includes a fast 3-second EpiLight, as well as an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals.  This complete package enables users to perform PhotoRejuvenation and hair removal, and is superior to an IPL Quantum SR combined with an IPL Quantum HR. One-year warranty on the EpiCool and EpiLight is included.  Full training and one year update is also included.



EpiCool Gold using VascuLight-HR

This package includes an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals, and an IPL-Rejuvenation for VascuLight-HR (3-second) provided by the customer. One-year warranty on the EpiCool system and VascuLight-HR is included.  Full training and one year manual update is also included. This complete package enables users to perform PhotoRejuvenation and hair removal in addition to comfortable leg vein treatments, using an existing VascuLight-HR system, with the peace of mind on all aspects of servicing the entire equipment.



EpiCool Gold using EpiLight

This package includes an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals, and an IPL-Rejuvenation for an EpiLight (3-second) provided by the customer. One-year warranty on the EpiCool system and EpiLight is included. Full training and one year manual update is also included. This complete package enables users to perform PhotoRejuvenation and hair removal using an existing EpiLight system with the peace of mind on all aspects of servicing the entire equipment.



EpiCool Silver using VascuLight-HR

This package includes an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals, for a VascuLight-HR (3-second) provided by the customer. This package enables users to perform PhotoRejuvenation and hair removal in addition to comfortable leg vein treatments, using an existing VascuLight-HR system.



EpiCool Silver using EpiLight

This package includes an EpiCool system with all of the necessary PhotoFace Rejuvenation manuals and crystals, for an EpiLight (3-second) provided by the customer. This complete package enables users to perform PhotoRejuvenation and hair removal using their existing EpiLight system.



Becoming a Distributor

OptoGenesis is willing to enter into a reseller agreement with qualified distributors who are willing to undergo certification.  For information about qualifying as a distributor, contact: Dr.gee@optogenesis.com
